AlexMos 32 bits Gimbal Strong Motor Encoder Kit

Build Your Own Strong Motor Gimbal Kit!

SKU:2SGRNL1827
Init A Live Chat Session For Any Question

*

*

*

*

*
$81.18
excluding shipping

AlexMos 32 bits
Strong Motor Integration Gimbal Kit

Product Description:

This AlexMos kit is an authorized licencing BASECAM electronics product.

Alexmos 32 bits
Stator diameter 43mm

Package included:

– 1 x 32Bit main board
– 1 x Motor with encoder
– 1 x IMU
– 1 x Slipring
– External output cables
– Can operate as single tilt axis, pan / tilt axis or yaw pan tilt axis depending how many motors you ordering.

Input power: 3S Li (11V) or up to 6S with external voltage regulator
Operating Current:
Attitude control accuracy: ± 0.02 degrees
Controllable rotation range
Rotation direction (PAN): ± 360 ° unlimited turns
Tilt direction (TILT): ± 360 ° unlimited turns
Rolling direction (ROLL): ± 360 ° unlimited turns
SBUS / PPM / SPI receiver support
Alexmos 32 bits licensed version
Ubec +5v 1A max

Model

4310

4315

6010

Weight (g) W/O encoder housing

112

158

235

Stator dimension (mm)

43x10

43x15

60x10

Configuration

24N28P

24N28P

245N28P

Turns

60

60

90

Voltage (V)

12-24

12-24

12-24

Torque

Resistance (Ohm)

11.0

15.2

10.3

Weight of gimbal with camera (g)

1000-2000g

1500-3000g

2500-4000g

Encoder

AS5048A

AS5048A

AS5048A

Encoder connector

Standard PWM, SBUS (optional: SPI)

Standard PWM, SBUS (optional: SPI)

Standard PWM, SBUS (optional: SPI)

Slip ring

12.5mm

12.5mm

12.5mm or 22mm

Documentation link
Basecam Official Documentation

Tuning Guide:

- We recommend to NOT UPGRADE THE ALEXMOS KIT TO THE LATEST VERSION OR YOU WILL BRICK IT

- THIS IS NOT A PLUG AND PLAY DEVICE! Brushless gimbals and controllers are very new to the market and is an emerging technology. You will need some patience and effort to get it to work as seen in many youtube videos. We can assist you while setting up the devise.

- This product has no protection circuit, it will be damaged due to power supply polarity reversed; wrong motor will burn down driver IC; Also, incorrect connection of attitude sensor will burn down the voltage regulation unit. The cases above are not covered under the warranty.

NOTE:

We carry this product is for customer’s convenience to purchase. We will always assume you are capable of handling this kind of open source project by yourself as we can’t provide comprehensive technical support as you may expect. And we don’t recommend this product if you don’t have confidence to use it. Please refer to the official website and related forums for the open source project if you have any questions.

PLEASE NOTE sliprings cables does not have any pins management
You will need to wire them directly to the encoder by soldering them to the board
